ECV-600 Video Colonoscope
CMOS HD option
₦1.00
Technical Specifications
Item | Video Colonoscope |
Diameter of Distal-end | Φ13.0mm |
Diameter of Insert Tube | Φ12.8mm |
Clamp Aperture | Φ 3.8mm |
Working Length | 1350mm |
Total Length | 1650mm |
View of field | 140 º |
Depth of view | 3-100mm |
Resolution | CMOS1,000,000 Pixels high resolution |
Tip Deflection | up 180° down 180°L/R 160° |
6.ECV-600 Video Colonoscope
– Bending operation: Traction chain structure, whole sealed waterproof.
– Image display: Two image display optional.
– Split machine: Main part and light source are split.
– Warranty: One year (free), permanent repairs (not free).
– Package size :64*18*48cm (G.W.: 5.18kgs).
7.EMV-9000 Video Processor and LG-880 Light Cold Source Machine
Parameters | Specifications |
Lamp | LED light (80W white) |
Power | 220-240V; 50-60HZ |
Color temperature | ≥5300K ,140000lx illumination |
Brightness | 0-10 level adjustable |
Video signal output | HDMI x2, DVI |
Air pump pressure | 30-60Mpk |
Air pump power | Strong/medium/weak 3 level adjustable |
Air flow | 4-10 L/min |
Sharpness adjustment | Supports automatic and manual modes, the manual mode supports 0-10 level adjustment |
Withe balance | It supports 4 kinds of fixed white balance parameter selection, real-time dynamic white balance mode and manual white balance parameter setting mode, or one click white balance |
Gain function | It supports automatic and manual modes, and the manual mode supports 0-16 level gain adjustment and 0-30 level exposure time adjustment |
Vascular enhancement | Can increase vascular clarity |
Electronic amplification | Support 1.2/1.5/1.7/2.0 times 4-gear electronic amplification function |
Bad point correction | Support 0-6 level image bad point correction |
Package size | 55*46*50cm (G.W.:20kgs) |
Function | Image adjustment: supports 0-100 level brightness, contrast and saturation adjustment |
Support full screen image freezing and half screen mode to freeze large images and dynamically display small images | |
With USB interface support picture and video record function and pictures playback function | |
Support connect same series Video bronchoscope , laryngoscope , Cystoscope ,Ureteroscope share this tower use |
LCD Monitor
– Display size: 24”
– Power Supply: External Power Supply 12V
– Resolution: 1280×1024
– Display Ratio: 16:9
– Color: 16.7M
– Camoration Brightness: 180±10 cd/m2
– Max. Brightness: 400 cd/
– Package size: 44*36.5*16.5cm (G.W.:6.0kgs)
Equipment Vehicle
– Size: 500*700*1350mm
– Package size: 127*63.5*22cm (G.W.: 36kgs)
Video Colonoscopy Endoscope Packing List
Name | Unit | Qty. |
ECV-600 Video Colonoscopy Configuration | ||
ECV-600 Video colonoscopy | Set | 1 |
Biopsy forceps | Set | 2 |
Cleaning brush | Set | 2 |
Leak tester | Set | 1 |
Attract valve cover | Set | 2 |
Water bottle sealing ring | Set | 6 |
Ear syringe | Set | 1 |
Water bottle assembly | Set | 1 |
Box | Set | 1 |
Scope lines | Set | 1 |
Manual | PC | 1 |
EMV-9000 Image processor | Set | 1 |
Video cable | Set | 1 |
U disk | PC | 1 |
Power line | Set | 1 |
Manual | PC | 1 |
LG-880 cold light source | Set | 1 |
Power line | Set | 1 |
fuse | Set | 2 |
Manual | PC | 1 |
24” HD LCD Monitor | Set | 1 |
Trolley | Set | 1 |
